PTFE Zebra Heat Shrink Flexible Tubing 150cm 450cm
The PTFE Zebra Heat Shrink Flexible Tubing (150cm/450cm) is a PTFE heat-shrinkable tubing that emphasizes high flexibility and fixed lengths. Made from modified PTFE material using flexible molding and heat-shrink technology, the tubing features a distinctive zebra stripe pattern. It is available in fixed lengths of 150cm, 450cm, and other lengths, and can be cut to size as needed. The product combines the temperature resistance, corrosion resistance, and insulation properties of PTFE material with excellent flexibility.
Product Features
High Flexibility
Made from modified PTFE material, its flexibility far exceeds that of ordinary PTFE heat-shrink tubing. It can be freely bent and folded, maintaining good flexibility after shrinking, making it suitable for protecting parts that require bending and dragging.
Convenient Fixed Lengths
Available in specific fixed lengths such as 150cm and 450cm, eliminating the need for additional cutting and splicing. It can directly fit parts with different length requirements, reducing cutting waste and improving operational convenience.
Easy Management with Zebra Markings
The clear zebra stripe markings on the tubing allow for quick differentiation of tubes with different uses and lengths. This does not affect the flexibility or shrinkage performance of the tubing, facilitating classification and maintenance.
Advantages
Flexible Protection without Restriction
High flexibility design allows for free bending and folding, suitable for protecting curved parts and moving components.
01
Cost-Saving Fixed Length Design
Different fixed lengths such as 150cm and 450cm meet the length requirements of different scenarios, while reducing inventory pressure and improving cost-effectiveness.
02
High Temperature and Corrosion Resistance
Retains the core advantages of PTFE material, capable of long-term resistance to temperatures from -60℃ to 260℃, ensuring a long service life.
03
Excellent Insulation Performance
Insulation strength up to 15-20kV/mm, effectively isolating current and signal interference, suitable for insulation protection of wires, connectors, and other components.
04
Convenient Cutting and Wide Applicability
Can be quickly cut to any length according to actual needs, accommodating the protection needs of both small instruments and large equipment.
05
Applications
Medical Flexible Instruments
Provides overall protection for disposable flexible guidewires, flexible catheters, and other instruments. The 150cm size is suitable for conventional flexible instruments, while the 450cm size is suitable for long interventional catheters. Protection performance is not affected by bending.
Electronic Device Wires
Used for protecting flexible wires and movable interfaces in electronic devices and precision instruments, such as endoscope equipment wires and portable medical instrument wires, preventing wire wear and short circuits, and ensuring stable signal transmission.
Industrial Moving Parts
Suitable for protecting moving transmission parts and flexible pipelines in industrial equipment, such as robot joint wires and special equipment flexible interfaces. Its high flexibility and temperature resistance ensure the normal operation of the components.
FAQ
Q: What is PTFE Zebra Heat Shrink Tubing used for?
A: PTFE Zebra Heat Shrink Flexible Tubing is mainly used for protecting flexible components that require longer tubing lengths and bending capability.
Q: What lengths are available for PTFE Zebra Flexible Heat Shrink Tubing?
A: Our standard lengths are 150 cm and 450 cm; custom lengths are also available upon request.
Q: Can this PTFE flexible heat-shrink tubing be used for medical devices?
A: Yes.Many medical device manufacturers use PTFE tubing for:Guidewire protection, catheter assemblies, endoscopy-related components, and other medical equipment.
Q: Why does the tubing have zebra markings?
A: The zebra stripe design helps customers quickly identify different tubing sections during manufacturing and assembly.
Q: Is PTFE Zebra Flexible Heat Shrink Tubing resistant to chemicals?
A: Yes.PTFE is renowned for its excellent chemical resistance, capable of withstanding a wide range of chemicals, solvents, and cleaning agents.
Q: Can the PTFE tubing be bent after shrinking?
A: Yes.PTFE heat-shrink tubing retains good flexibility and bending properties even after the shrinking process.
Q: What information do you need for a PTFE flexible heat shrink tubing quotation?
A: we need to know: required length, inner diameter (ID), outer diameter (OD), shrink ratio, application scenario, and annual usage or order quantity.
If you have drawings or samples, we can assist in recommending the appropriate specifications.
Q: Can you produce customized PTFE heat shrink tubing lengths?
A: Yes.We support custom production, including: special lengths, various diameters, different colors, and OEM packaging.
Q: How do you control the quality of PTFE heat shrink tubing?
A: We control quality throughout the production process, including: raw material inspection, extrusion process monitoring, dimensional checks, shrinkage performance testing, and final visual inspection.
Technical Specifications
|
Expanded ID Min: |
0.45-0.98mm(0.018''-0.038'') |
|
Recovered Wall Max: |
0.05mm and above |
|
Length: |
Max 450cm |
|
Stripe direction: |
Left-hand or right hand rotation available |
|
Pitch: |
Max 16 stripes / inch |
|
Color: |
Yellow/Black |
|
Blue/White |
|
|
Black/White |
|
|
Green/White |
|
|
Blue/Yellow |
